Specifications
- Additional Glazing Information
- Screen printed lines
- Beading Additional Information
- Beading on this door is plastic and suitable for painting but must be primed and undercoated in order for paint to adhere properly
- Beading Material
- PVC
- Colour Description
- White
- Construction
- Moulded
- Construction Material
- HDF
- Core Material
- Honeycomb (25mm cell width)
- Door Construction
- Constructed using softwood timber stile and rail frame
- Door Finish
- Smooth
- Door Finish Type
- Primed
- Door Location
- Internal
- Finish With
- Paint
- Glazed
- Glazed
- Glazing
-
- Supplied with clear toughened etched glass
- Glazing Fixing Method
- Beading and Pinned
- Glazing Type
- Toughened
- Glue/Resin
-
- Melamine Urea Formaldehyde
- Lipping Details
- Lipped on two long edges
- Moisture Resistant
- Not Moisture Resistant
- Number of Lights
- 1
- Number of Panels
- 5
- Product Type
- Glazed
- Range Name
- Dordogne
- Timber Species
- Softwood, sawfilling grade
- Veneered
- Not Veneered
Product Measurements
- Bottom Rail
- 185mm
- Door Lipping Thickness - Bottom
- 10mm
- Door Lipping Thickness - Sides
- 10mm
- Door Lipping Thickness - Top
- 10mm
- Glazing Height
- 1679mm
- Glazing Thickness
- 4mm
- Glazing Width
- 446mm
- Height
- 1981mm
- Height (Imperial)
- 6'6"
- Stile
- 120mm
- Thickness
- 35mm
- Top Rail
- 117mm
- Weight (Without Packaging)
- 12.04kg
- Width
- 686mm
- Width (Imperial)
- 2'3"
Guarantees & Accreditations
- Accreditation BSI
-
- BS EN 12150
- Certification
- Glazing certificate available
- Fire Rating
- Not Fire Rated
- Timber Certification
- FSC
- UK Manufactured
- Guarantees and accreditations
Installation
- Door Edging Maximum Trim Bottom
- 6mm
- Door Edging Maximum Trim Each Side
- 6mm
- Door Edging Maximum Trim Top
- 6mm
- Edging Additional Information
- An equal amount of timber should be removed from each side/ top & bottom. Remaining within the parameters of the maximum trim instructions ensures the construction of the door is not compromised.
- Fitting Instructions
-
- Please refer to door instructions for all fitting information.
- This door can be rebated.
- For identification, the Howdens logo, SKU code and batch number is on the top edge of the door.
- Lock Block Height
- 360mm
- Lock Block Position
- Fitted centrally, to one side only - If the lock block is not indicated by the word 'LOCK' on the top edge, a hole will always be visible on the bottom edge on the side of the lock block.
- Lock Block Width
- 65mm
