Specifications
- Colour Description
- Oak
- Construction
- Stile and Rail
- Construction Material
- Oak Veneer
- Core Material
- Particleboard
- Door Construction
- Veneered particleboard
- Door Finish Type
- Pre-Finished
- Door Location
- Internal
- Glazed
- Glazed
- Glazing
-
- Supplied with clear toughened etched glass
- Glazing Fixing Method
- Cramp Glazed (Glass cannot be replaced)
- Glazing Stamp Details
- Howdens glazed doors do have Kite marks, however they are not legally required to be on every door.
- Glazing Type
- Toughened
- Glue/Resin
-
- PVA
- Lipping Details
- Lipped on two long edges
- Material
- Inserts made from local hardwood or American White Oak
- Moisture Resistant
- Not Moisture Resistant
- Number of Lights
- 1
- Number of Panels
- 5
- Product Type
- Glazed
- Range Name
- Genoa
- Surface Veneer Thickness
- 0.6mm
- Timber Species
- American White Oak
- Time Saving
- Saving 4 to 6 hours on finishing time
- Veneer Grade
- A
- Veneer Timber Species
- American White Oak
- Veneered
- Veneered
Product Measurements
- Bottom Rail
- 180mm
- Door Lipping Thickness - Bottom
- 11mm
- Door Lipping Thickness - Sides
- 11mm
- Door Lipping Thickness - Top
- 11mm
- Glazing Height
- 1686mm
- Glazing Thickness
- 4mm
- Height
- 1981mm
- Height (Imperial)
- 6'6"
- Stile
- 120mm
- Thickness
- 35mm
- Top Rail
- 115mm
- Weight (Without Packaging)
- 23.763kg
- Width
- 686mm
- Width (Imperial)
- 2'3"
Guarantees & Accreditations
- Accreditation BSI
-
- BS EN 12150
- Certification
- Glazing certificate available
- Fire Rating
- Not Fire Rated
- Guarantee
- 5 Year Manufacturer's Guarantee
- Guarantees and accreditations
Installation
- Door Edging Maximum Trim Bottom
- 3mm
- Door Edging Maximum Trim Each Side
- 3mm
- Door Edging Maximum Trim Top
- 3mm
- Edging Additional Information
- An equal amount of timber should be removed from each side & bottom. Remaining within the parameters of the maximum trim instructions ensures the construction of the door is not compromised.
- Fitting Instructions
-
- Howdens doors do have Kite markings, however it is not a legal requirement to be visible on every door.
- Please refer to door instructions for all fitting information.
- For identification, the Howdens logo, SKU code and batch number is on the top edge of the door.
- This door has a particleboard core which may be exposed if rebated. The use of the oak door pair maker is therefore recommended.
- Pre-finished with clear lacquer ready for installation.
- Can save the builder up to 6 hours on finishing
- Any trimmed edges and all cut outs for hardware must be refinished
- Lock Block Additional Information
- A lock block is not included on this door as it is a solid construction. The lock can be fitted in any location on either side, avoiding mid rail joints as this can weaken the structure of the door.
