Specifications
- Construction
- Flush
- Construction Material
- Plywood
- Core Material
- Flaxboard
- Decibel Reduction
- 31
- Door Construction
- Constructed using softwood timber stile and rail frame
- Door Finish Type
- Unfinished
- Door Location
- Internal
- Finish With
- Paint
- Glazed
- Unglazed
- Intumescent Strip Details
-
- 15 x 4mm intumescent strip pre-fitted to top edge of door
- Lipping Details
- Lipped on two long edges
- Lipping Material
- Hardwood
- Moisture Resistant
- Not Moisture Resistant
- Product Type
- Fire
- Range Name
- Spey
- Surface Veneer Thickness
- 3mm
- Timber Species
- Red Meranti
- Veneer Grade
- Paint grade surface veneer
- Veneer Specification
- Plywood
- Veneer Timber Species
- Red Meranti
- Veneered
- Veneered
Product Measurements
- Door Lipping Thickness - Bottom
- 10mm
- Door Lipping Thickness - Sides
- 6mm
- Door Lipping Thickness - Top
- 6mm
- Height
- 1981mm
- Height (Imperial)
- 6'6"
- Inner Rail
- 28mm
- Stile
- 23mm
- Thickness
- 35mm
- Weight (Without Packaging)
- 25.882kg
- Width
- 838mm
- Width (Imperial)
- 2'9"
Guarantees & Accreditations
- Accreditation BSI
-
- BS 476-22:1987
- Building Regulations
-
- Part M
- Certifire Approval
- Certifire Approved
- Fire Rating
- FD30
- UK Manufactured
- Guarantees and accreditations
Installation
- Door Edging Maximum Trim Bottom
- 6mm
- Door Edging Maximum Trim Each Side
- 4mm
- Edging Additional Information
- An equal amount of timber should be removed from each side & bottom. Remaining within the parameters of the maximum trim instructions ensures the construction of the door is not compromised and that the door when fitted complies with the fire certificate.
- Fitting Instructions
-
- Please refer to door instructions for all fitting information.
- All fire doors must be fitted in accordance with the fire certificate.
- For identification, the Howdens logo, SKU code and batch number is on the top edge of the door.
- This door is compatible with VOC 2010 compatible finishes and the use of water based primers and paints will not adversely effect the integrity of the door.
- Lock Block Additional Information
- A lock block is not included on this door as it is a solid construction. The lock can be fitted in any location on either side.
